IEI PM-P006UPS-R10 65W ATX DC/DC 6-36VDC Input, 12V, 5V, 3.3V, -12V and 5VSB Output, w/ UPS, Power Module
Images shown for reference only
IEI PM-P006UPS-R10 65W ATX DC/DC 6-36VDC Input, 12V, 5V, 3.3V, -12V and 5VSB Output, w/ UPS, Power Module Power Module

Shipping Extra
ATACOM Part #: IPMD_IEIX_06_53
   Price: $245.95


Brand IEI
Model PM-P006UPS-R10
Input

6 VDC to 36 VDC
Output

max.: 12 V@4 A, 5 V@10 A, 3.3 V@8 A, 5 VSB@1 A,& -12 V@0.1 A
Max. total output: 65 W
Efficiency

up to 90%
Storage Temperature

40ºC ~ 125ºC

Operating temperature

-20°C~85°C
1. Load down protection
2. Over voltage protection
3. Short circuit protection
4. Over current protection
5. Smart battery charger for Lithium Ion
6. I/O interface: SMBus/I2C & RS-232
7. Support up to 2 battery packs
8. AT/ATX modes
9. Utility program: pull data out through RS-232 to a system
